Segmented body design, can be produced according to thesize of cloth.
FEATURES AND FUNCTIONS
1. Segmented body design, can be produced according to thesize of cloth.
2.It can be used to produce large wet wipes, increase theliquid measurement of different varieties.
3.It can be used with right Angle and rounded corner, noedge,no waste.
4. The product is beautiful and convenient to switch freely. Thecloth can be folded in half, three fold and four fold into thebag.
5. The upper and lower winding film can be installed sepa-rately, and the pattern of the automatic version is accurate.and the left and rightedges adjust position automatically andaccurately.
6. The finished product can be cut with dotted lines, and thenumber of packages can be cut according to the require-ments.The package can be rolled and not broken.
MAIN TECHNICAL PARAMETERS
| PACKAGING MATERIAL | Paper aluminum-plastic, cloth roll (knitted fabric) |
| PACKAGING FILM WIDTH | 55*50mm(L*W) |
| COTTON SWAB MATERIAL | Inner cloth:150g/m² After sliting: 35*30mm(L*w),Do not fold |
| FILLING SPEED | 8row500-1200 slice(Eight out of one) |
| FILLING RANGE | 1ml （Alcoholic liquid）, ±0.5ml(The filling accuracy is 0.5ml） |
| POWER SUPPLY | 380V 50/60Hz5.5Kw |
| MACHINE SIZE | 3800*1200*1500mm(L*W*H) |
| MACHINE WEIGHT | 1100 kg |
